KOOLNOVA AIR CONTROL ACNH-GTP-UNI4 Wired Fan-Coil Interface for Ducted Hydronic Fan-Coils - 2 Speeds

KoolNova Air Control ACNH-GTP-UNI4 Fan-Coil interface, with wired communication (2 speeds), for the control and management of ducted hydronic fan-coils in zoning air conditioning systems.
€284.00
KOOLNOVA AIR CONTROL ACNH-GTP-UNI4 Wired Fan-Coil Interface for Ducted Hydronic Fan-Coils - 2 Speeds is available to buy in increments of 1
Order now for delivery between 12 November and 17 November

KoolNova Air Control fan-coil interfaces allow for both switching on/off and changing the operating mode (cooling/heating) of ducted fan-coils, as well as managing their speed (0-10V output available). Configurable for both production control and hydronic terminal control, these devices offer 4 connection possibilities.

Features:
- KoolNova BUS connection input;
- Two-wire non-polarized connection;
- Isolated relay output for fan-coil ON/OFF control;
- Isolated relay output for system production control;
- Isolated relay output for 3-speed control (UNI2);
- Isolated relay output for 2-speed control (UNI4);
- 0-10V output for fan-coil speeds;
- Unit (AC) selection via DIP switches;
- Operating mode control (cooling or heating);
- LED operation indicators;
- Power supply: 230 V~ 50/60Hz;
- Supply voltage: 90-264 Vac;
- Frequency range: 47-63 Hz;
- Maximum power: 3.5W;
- Class II;
- Weight: 139 grams.

More Information
Dimensions (LxHxD) mm 54x90x61
Weight (Kg) 0.139
